Shenzhen Hpmont Technology Co., Ltd Chapter 8 Troubleshooting
HD5L Series Controller User Manual 101
Fault code Fault name Possible reasons of fault Counter-measures
E0021
Controlboard
EEPROM faulty
Memory circuit fault of control
board EEPROM
Please contact the supplier for
repairing
E0022
Panel EEPROM
faulty
Memory circuit fault of panel
EEPROM
Replace the panel
Please contact the supplier for
repairing
E0023
Parameter setting
faulty
The power rating between
motor and controller is too
different
Improper setting of motor
parameters
Select a controller with suitable
power rating
Please set correct value of motor
parameters
E0024 External faulty
Fault terminal of external
equipment operates
Please check external equipment
E0028 SCI timeout faulty
Connection fault of
Communication cable
Disconnected or not well
connected
Please check the connection
E0029 SCI faulty
Connection fault of
Communication cable
Disconnected or not well
connected
Communication setting error
Communication data error
Please check the connection
Please check the connection
Please correctly set the
communication format and the
baud rate
Send the data according to
MODBUS protocol
E0030 PG direct wrong
PG wire phase and motor
phase are not match
Set the reverse value of F11.02
E0031 PG disconnection PG without input signal Check the PG connection
E0032 Motor over speed
PG pulse number fault
Inadequate controller torque
Speed-loop PI parameter
setting isn’t correct
Set proper PG pulse number
Select biger capacity controller
Correctly set speed-loop PI
parameter
E0033
Loss of Z signal of
ABZ encoder
Connection problem
Severe interference
Check the connection
E0034
UVW signal
wrong of UVW
encoder
UVW PG fan-area error Check the UVW connection
E0035
CD phase wrong
of SINCOS
encoder
PG fault
PG disconnection
Check the PG
Check the PG connection
E0036 Contator faulty
Contactor damage
Feedback contact connection
problem
Change the contactor
Check the connection
123
Mark: E0022 doesn’t affect the controller normal operation.
