6.2.2 Group F01 Protection of Parameters
Code Name Description Range
【
factory setting
】
F01.00 User password 00000
－
65535
【
00000
】
XXXXX: To enable the password protection function, set any non-zero number as the password.
• Once the password is set, and detect that there is no press on the panel within 5 minutes, the
user’s password will be valid.
• It is necessary to input correct password if you want to change the parameters. Otherwise you can
not change any parameter via panel, but only check.
00000: The factory setting and no user’s password.
• If the user unlocks the password, it means clearing the user’s password.
• To unlock, change and clear the user’s password, see section 5.2.3.
F01.01 Menu mode 0,1
【
0
】
0: Full menu mode. All function parameters can be displayed in this menu.
1: Checking menu mode. Only different from factory setting parameters can be displayed.
F01.02 Parameter initialization 0
－
3
【
0
】
0: No operation. The controller is in regular parameter read/write state.
• Whether can change the parameter it depends on the user’s password state and the actual
operating conditions.
1: Restore to factory settings.
• Except Group F01, F07.00－F07.14, Group F10, Group F11, F15.00, F17.11－F17.27, Group
F18 and Group Y.
• Operation steps: If set F01.02 = 1, press to ensure and the parameters are restored to
factory settings. The panel dispalys “loading defualt para.”. Then the panel will display
parameters in stop state after finish restoring to factory setting.
2: Parameter download.
• Except Group F01, F17.11－F17.27, Group F18 and Group Y.
• Motor parameters, encoder parameters and magnetic pole angle etc. will be downloaded.
Record the original parameters such as motor parameters, encoder parameters and magnetic
pole angle etc. Or restart parameter auto-tuning.
3: Clear fault information. The fault history of F17.11－F17.27 will be clear.
F01.03 Panel EEPROM parameter initialization 0,1
【
0
】
0: No operation. The controller is in regular parameter read/write state.
1: Parameter upload. Upload the present function code settings to the panel EEPROM parameter.
Note: Group F01, F17.11
－
F17.27, Group F18 and Group Y do not upload.
