Chapter 10 Accessories Shenzhen Hpmont Technology Co., Ltd
―108― HD5L Series Controller User Manual
10.2 Braking Resistor Selection
The braking resistor selection is listed as Table 10-1.
Refer to section 4.3.2 for the brake resistor connection.
Table 10-1 Braking resistor selection
Model Moor
Recommend value (Ω) Recommend power (kW)
Min Max
Recommended
value
Synchronous Asynchronous
HD5L-2S2P2 2.2 kW 26 130 50 1 1
HD5L-2S3P7 3.7 kW 26 90 30 1.6 1.2
HD5L-4T2P2 2.2 kW 56 210 100 1 1
HD5L-4T3P7 3.7 kW 56 144 80 1.6 1.2
HD5L-4T5P5 5.5 kW 56 100 70 2 1.6
HD5L-4T7P5 7.5 kW 56 72 64 3.2 2
HD5L-4T011 11 kW 34 48 40 4 3.2
HD5L-4T015 15 kW 34 41 36 5 4
HD5L-4T018 18.5 kW 17 31 24 6.4 5
HD5L-4T022 22 kW 17 27 20 8 6.4
HD5L-4T030 30 kW 11 20 15 10 8
HD5L-4T037 37 kW 10 16 12 12 10
HD5L-4T045 45 kW 7 10 9 18 15
10.3 Protective Cover
The protective cover is an accessory. If needed, please order goods.
Model: HD-CK-Frame4. The protective cover is applied to plastic structure controller (18.5kW
and below model), and each controller needs 2 protective covers.
10.4 Power Regenerative Unit
Please refer to HDRU Series Power Regenerative Unit User Manual for more details.
