Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―60― HD5L Series Controller User Manual
Code Name Description Range
factory setting
F00.05 Operating mode 0
5
0
0: Panel control.
• Controlled by pressing the or key of the panel. Set the run speed in F00.07.
1: Terminal analogue control.
• The run command is controlled by UP and DN of the terminal; and the run speed is set by
analogue input terminals.
2: Terminal MS control.
• The run command is controlled by UP and DN of the terminal; and the run speed is set by MS1－
MS3 multi-step speed terminal combination.
3: Reserved.
4: SCI control.
• The run command and the run multi-step speed are set by PC communication.
5: Reserved.
F00.06 M-key function 0,1
0
0: Disable.
1: UP/DN switch.
F00.07 Speed setting of panel 0.000
F00.02
1.500m/s
When F00.05 = 0, it set the objective speed at running.
F00.08 Run direction 0,1
0
0: The same as run command.
1: Opposite to run command.
To Next Page
