hpmont HD5L series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―110― HD5L Series Controller User Manual
Code Name Range Default Unit Attributes Setting
Group D00 System State Parameters (on pages 54
－
55)
D00.00 Controller series HD5L Actual value *
D00.01 DSP software version 0.00－9.99 Actual value *
D00.02
DSP special software
version
0.00－9.99 Actual value *
D00.03 Panel software version 0.00－9.99 Actual value *
D00.04 Elevator running state
Display in 16-bit binary:
Bit0: Controller enable
Bit1: Inspection run
Bit2: MS run
Bit3: Analogue run
Bit4－Bit7: Reserved
Bit8: Brake feedback input
Bit9: Contactor feedback
input
Bit10: Up forced Dec input
Bit11: Down forced Dec input
Bit12: MS terminal 1
Bit13: MS terminal 2
Bit14: MS terminal 3
Bit15: Battery driven run
Actual value *
D00.05 Rated current 0.1－999.9A Actual value *
D00.06 Controller state
Display in 16-bit binary:
Bit0: Controller fault
Bit1: Run/stop
Bit2: UP
Bit3: DN
Bit4&5: Acc/Dec/constant
Bit6: Zero-speed signal
Bit7: Run at zero-speed
Bit8: Auto-tuning
Bit9: Speed arrived
Bit10: Ready to run
Bit11: Brake output
Bit12: Contactor output
Bit13: Stop signal
Bit14,Bit15: Reserved
Actual value *
Group D01 Drive State Parameters (on pages 55
－
56)
D01.00 Control mode 0－5 Actual value *
D01.01 Setting speed(m/s) 0.000－9.999 Actual value *
D01.02
Setting speed (after
acc/dec)(m/s)
0.000－9.999 Actual value *
D01.03 Feedback speed(m/s) 0.000－9.999 Actual value *
D01.04 Setting frequency (Hz) 0.01－100.00Hz Actual value *
D01.05
Setting frequency (after
0.01－100.00Hz Actual value *
