Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―112― HD5L Series Controller User Manual
Code Name Range Default Unit Attributes Setting
D03.03 MODBUS state
0: Normal
1: Communication timeout
2: Incorrect data frame head
3: Incorrect data frame
checking
4: Incorrect data frame
content
Actual value *
D03.04
Total time at
power-on(Hour)
0－65535 Actual value *
D03.05 Total running time 0－65535 Actual value *
D03.06 Run times 0－65535 Actual value *
D03.07 Present fault 0－100 Actual value *
Group D04 Encoder State Parameters (on pages 58
－
59)
D04.00
C phase value of
SINCOS encoder
0－4095 Actual value *
D04.01
D phase value of
SINCOS encoder
0－4095 Actual value *
D04.02
A phase value of
SINCOS encoder
0－4095 Actual value *
D04.03
B phase value of
SINCOS encoder
0－4095 Actual value *
D04.04
UVW state of UVW
encoder
0－7 Actual value *
D04.05 Electrical angle 0－65535 Actual value *
D04.06－D04.7 Reserved
D04.08 Pulses of PG 0－65535 Actual value *
D04.09－D04.11 Reserved
Group F00 Basic Parameters (on pages 59
－
61)
F00.00 Motor type
0: Asynchronous
1: Synchronous
0 1 ×
F00.01 Control mode
0: V/f
1: Sensorless vector control
2: Closed-loop vector control
2 1 ×
F00.02 Elevator rated speed 0.100－4.000m/s 1.500m/s
0.001
m/s
×
F00.03
Controller max output
freqency
5.00－100.00Hz 50.00Hz 0.01Hz ×
F00.04
Traction machine
mechanical parameters
10.0－6000.0 60.0 0.1 ×
F00.05 Operating mode
0: Panel control
1: Terminal analogue control
2: Terminal MS control
3: Reserved
4: SCI control
5: Reserved
0 1 ×
