Shenzhen Hpmont Technology Co., Ltd Chapter 2 Product Information
HD5L Series Controller User Manual ―5―
Item Specification
I/O feature
Analogue supply
+10V, maximum current 100mA
-10V, maximum current 10mA
Digital supply +24V, maximum current 200mA
Analogue input
AI1 (control board): voltage 0－10V
AI2, AI3 (control board): -10V－+10V/0－20mA (voltage/current is
selectable)
AI4 (I/O card): -10V－+10V/0－20mA (voltage/current is selectable, and
differential input is supported)
Analogue output AO1, AO2: 0－10V/0－20mA (voltage/current is selectable)
Digital input DI1－DI6 (control board); DI7－DI12 (I/O card)
Digital output DO1, DO2
Programmable relay
output
R1A/R1B/R1C (control board)
R2A/R2B/R2C; R3A/R3B/R3C; R4A/R4B/R4C (I/O card)
Contact rating 250VAC/3A or 30VDC/1A
Communi-
cation
SCI communication RS-485 interface
Panel
LCD display
Function parameter setting, check the state parameters and the fault code
etc.
Parameter copy To achieve quick parameter copy
Environment
Operation temperature
-10－+40℃, air temperature fluctuation is less than 0.5℃/min
The derating value of the output current of the controller shall be 2% for each
degree centigrade above 40℃. Max. allowed temperature is 50℃
Storage temperature -40－+70℃
Location for use
Indoor, preventing from direct sunlight, no dust, corrosive, flammable gases,
oil mist, water vaper, dripping or salt etc.
Altitude Less than 1000 meters, otherwise should be derating use
Humidity Less than 95%RH, non-condensing
Ocsillation Less than 5.9m/s
2
(0.6g)
Options
Encoder card
OC encoder card with frequency demultiplication output (HD-PG2-OC-FD)
SINCOS encoder card with frequency demultiplication output
(HD-PG5-SINCOS-FD)
Line drive encoder card with frequency demultiplication output
(HD-PG6-UVW-FD)
Serial Communication encoder card with frequency demultiplication output
(HD-PG9-SC-FD) (support Endat)
About panel
Mounting base to panel (HD-KMB)
1 meter extension cable to panel (HD-CAB-1M)
2 meter extension cable to panel (HD-CAB-2M)
3 meter extension cable to panel (HD-CAB-3M)
6 meter extension cable to panel (HD-CAB-6M)
Enhanced protection Protective cover (HD-CK-Frame4)
Power unit Power regenerative unit (HDRU)
