Fault auto-reset function and fault relay action (F17.08
－
F17.10)
Auto reset function enables the controller to reset the fault as per the preset times (F17.08) and
interval (F17.09).
The following faults do not have the auto reset function:
E0008: Power module faulty E0021: Control board EEPROM faulty
E0010: Brake unit faulty E0023: Parameter setting faulty
E0013: Soft start failed E0024: External faulty
E0014: Current detect faulty E0036: Contactor faulty
Code Name Description Range
【
factory setting
】
F17.08
Fault auto reset times
0－100【0】
F17.09 Fault auto reset interval 2.0
－
20.0
【
5.0s/times
】
When F17.08 = 0, it means “auto reset” is disabled and the protective device will be activated in case
of fault.
• If no other fault is detected within 5 minutes, the auto reset count will be automatically cleared.
• On condition of external fault reset, auto reset count will be cleared.
F17.10 Fault relay action select 00
－
11
【
00
】
Units: During auto reset
• 0: Fault relay doesn’t act.
• 1: Fault relay acts.
Tens: During DC bus low
• 0: Fault relay doesn’t act.
• 1: Fault relay acts.
Note: It need preset the relay function as No. 14 function. (Controller fault)
