(1) TAPERED END
(2) FORK SPRING
Install the fork spring into the fork slider with the
tapered end facing up.
(1) SPRING COLLAR
(2) FORK BOLT
Pull the damper rod up and hold it between the
spring coil as shown.
(1) OIL LEVEL
Slowly lower the slider, and gently seat the dust seal
onto the axle holder and leave it for 5 minutes.
After the oil level stabilizes, measure the oil level
from the top of the fork slider.
Be sure the oil level is the same in both forks.
2-34
Racing Kit
(2)
(1)
(1)
(2)
