HS-Technik NutBee NBPS-21 User Manual

- 34 -
 
19320012
DISABLE
HALT
The tool is not enabled.
P03001/003
OK
kN
7.15
mm
9.45
The rst of three rivet nuts was successful. Achieved force 7.15 kN and
a stroke of 9.45 mm. This message is also available as a NOK noce.
HST-Tool-Manager display seng:
Signals - OLED-display - Display of results: Smiley
P01001/003
OK 2
kN
7.15
mm
9.45
7.15
The rst of three rivet nuts was successful. Achieved force 7.15 kN and
a stroke of 9.45 mm. This message is also available as a NOK noce.
HST-Tool-Manager display seng:
Signals - OLED-display - Display of results: Force
P01001/003
OK
kN
7.15
mm
9.45
OK 02
The rst of three rivet nuts was successful. In the visualisaon area, the
counter decreases as the remaining number of rivets is displayed. This
message is also available as a NOK noce.
HST-Tool-Manager display seng:
Signals - OLED-display - Display of results: Counter
P01001/003
OK 2
kN
7.15
mm
9.45
9.45
The rst of three rivet nuts was successful. Achieved force 7.15 kN and
a stroke of 9.45 mm. This message is also available as a NOK noce.
HST-Tool-Manager display seng:
Signals - OLED-display - Display of results: Stroke max.
P03002/002
All OK
All three seng processes were successful.
HST-Tool-Manager display seng:
Signals - OLED-display - Display of results: Big smiley
P01001/003
NOK
kN
7.39
NOK 03
mm
0.75
Example of the NOK seng process:
Process 1 NOK, 2 processes le. If NOK acknowledgement is acvat-
ed, the display must be acknowledged by pressing the yellow display
buon.
RSSI -0dBn
19.4
The baery voltage can be displayed in the Setup menu under
"features".
Tool is in idle mode. It can be
reacvated by pressing the Start buon.
For NOK results, the visualisaon area is framed in red and the green result display is also
red.
