CAUTION
Reserve the plastic screws for later use.
Figure 6-11 Installing the lifting lugs
(1) Plastic screw (2) Lifting lug
Step 2 Install ropes on the lifting lugs, and then lift the cabinet, as shown in Figure 2.
DBS3900 (Ver.B)
Installation Guide
6 Outdoor Scenario with AC Power Supply (BBU Installed
in an APM30H)
Issue 06 (2011-09-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
36
