Table 3-5 Technical specifications of the AGX105F door status sensor
Item Specification
Working voltage 250 V AC
Rated current 10.0 A
Pin length 10.60 mm [0.42 in.]
Table 3-6 lists the technical specifications of the HO-03A door status sensor.
Table 3-6 Technical specifications of the HO-03A door status sensor
Item Specification
Effect distance
≥ 25 mm [0.98 in.]
Contact capacity l Maximum voltage: 150 V DC
l Maximum current: 0.5 A
Impedance 0.3 ohm
Power 10 W
Output type Dry contact point
3.5 Humidity/Temperature Sensor
This describes the humidity/temperature sensor. The model of the configured humidity/
temperature sensor is WS302A1T4.
Exterior of the Humidity/Temperature Sensor
Figure 3-7 shows the exterior of the WS302A1T4 humidity/temperature sensor.
Figure 3-7 Exterior of the WS302A1T4 humidity/temperature sensor
