The internal resistance can be measured only when the batteries are fully charged and no alarm is
generated in the intelligent battery monitoring system. A measurement can be performed at least 45
minutes after the previous measurement ends. The battery internal resistance will change to an invalid
value after power-off and then power-on again. By default, the BIM checks the battery internal
resistance once every 24 hours as instructed by the CIM. The red indicator on the BIM is steady on
during the check. You can also measure the battery internal resistance manually.

On the CIM WebUI home page, choose Monitoring > CIM System > Running Control, set
Internal resistance, select the battery number from the range of 1–300, and click Submit to start
measuring the battery internal resistance.

On the UPS WebUI home page, choose Monitoring > Control > CIM Control, set CIM No. and
BIM No., and click Measure to start measuring the battery internal resistance.

On the UPS LCD home screen, choose System Info > Maintenance > CIM Control, set CIM No.
and BIM No., and click Measure to start measuring the battery internal resistance.
----End
5.5 Management System Parts Replacement
5.5.1 Replacing an ECC800 Subrack
Prerequisites

Replace an ECC800 subrack after power-off.

Before removing the ECC800 monitoring module, label the cables connected to the
monitoring module based on the corresponding ports and disconnect the cables from the
monitoring module. If you do not disconnect the cables, check that the cables are still
connected securely after replacing the ECC800 subrack.

Tools: insulation gloves, Phillips screwdriver, labels, and marker

Materials: a reserved undamaged and undeformed ECC800 subrack of the appropriate
model
Procedure
Step 1 Switch off the upstream input circuit breaker for the ECC800 and remove the power plug
from the rear of the ECC800.
Step 2 Remove the PSU and ECC800 monitoring module.
Step 3 Remove the screws from the mounting ears on both sides of the ECC800 subrack and remove
the failure ECC800 subrack.
Step 4 Screw the reserved ECC800 subrack to the position for the failure subrack.
Step 5 Reinstall the PSU and ECC800 monitoring module.
Step 6 Connect the power plug to the rear of the reserved ECC800 subrack and switch on the
upstream input circuit breaker for the ECC800.
