FusionModule5000 Smart Modular Data Center
Maintenance Guide (ECC800)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Step 7 Pull the handle on the cover to remove the cover, as shown by (7) in Figure 5-29.
Step 8 Replace the faulty component in the electric control box.
Step 9 Install the electric control box by following steps from Step 1 to Step 7 in the reverse order.
Step 10 Close and lock the rear door.
----End
5.2.3 Replacing an Air Filter
Prerequisites
The air filter needs to be replaced.
A spare air filter of the same model is available and functional.
Context
Preparation: maintain from the rear door.
Procedure
Step 1 Open the rear door.
Step 2 Rotate the baffle plate and remove the air filter.
Step 3 Install the spare air filter.
Step 4 Close and lock the rear door.
Step 5 Tap Maint > Performance Maint on the home screen to enter the performance maintenance
screen and clear the runtime of the air filter.
----End
5.2.4 (Optional) Replacing a Condensate Pump
Prerequisites
The condensate pump needs to be replaced.
A spare and functional condensate pump valve is available.
Context
Recommended tool: Phillips screwdriver
Preparations: The device is only maintained from the rear door, and is powered off.
Procedure
Step 1 Turn off all AC input switches.
Step 2 Open the rear door.
