Quidway S2000-EI Series Ethernet Switches Chapter 1 Product Overview
1-7
Table 1-6 Port LEDs on S2016-EI front panel
Status
mode LED
Port LED status Description
Flashing (faster for heavier
traffic, and nearly steady
ON when the traffic is
tremendous)
Traffic is being received or transmitted
on the port.
Yellow
(ACTIVE)
OFF
There is no traffic being received or
transmitted on the port.
ON A LINK is UP (correctly connected).
A/L mode
LED ON
Green
(LINK)
OFF
There is no link present (due to LINK
DOWN or ERROR).
ON The port is in full duplex mode.
Yellow
(DUPLEX)
OFF The port is in half duplex mode.
Flashing (at frequencies of
12 Hz)
The port operates at 100 Mbps
Flashing (at frequencies of 3
Hz)
The port operates at 10 Mbps
D/L mode
LED OFF
Green
(SPEED)
Steady ON There is no traffic on the port.
III. Fixed 100Base-T Ethernet ports on S2016-EI front panel
Table 1-7 Attributes of the fixed 100Base-T Ethernet ports on S2016-EI front panel
Attribute Description
Connector RJ-45
Number of ports 16
Port attribute
10 Mbps half/full duplex
100 Mbps half/full duplex
Standard IEEE 802.3u
Max. transmission segment length over
the selected medium
100 m (328 ft) over the category-5 twisted pair cable
IV. Console port
S2016-EI provides a Console port compliant with EIA/TIA-232 asynchronous serial
specifications. Through this port, you can configure the switch at the local or remotely.
