Quidway S2000-EI Series Ethernet Switches Chapter 4 Powering on Switch for the First Time
4-5
Select [Properties] in the HyperTerminal dialog box to enter the property window.
Click [Settings] in the property setting window as the following figure and select
VT100 as the emulation terminal. Click <OK> when the selection is done.
Figure 4-6 Setting terminal emulation in properties setting window
4.4 Boot Switch
4.4.1 Check before Powering on the Switch
Before powering on a switch, check whether:
z The power cord and ground wire are correctly connected.
z The voltage is consistent with that required by the switch.
z The Console cable is correctly connected, the terminal (which can be a PC) for
configuration has been started, and the configuration parameters have been set.
4.4.2 Powering on the Switch
After powering on the switch, run BOOTROM program first and the terminal yields the
following output:
