Quidway S2000-EI Series Ethernet Switches Chapter 1 Product Overview
1-11
Status
mode LED
Port LED status Description
ON The port is in full duplex mode.
Yellow
(DUPLEX)
OFF The port is in half duplex mode.
Flashing (at frequencies of
12 Hz)
The port operates at 100 Mbps
Flashing (at frequencies of 3
Hz)
The port operates at 10 Mbps
D/S mode
LED ON
Green
(SPEED)
Steady ON There is no traffic on the port.
III. Fixed 100Base-T Ethernet ports on S2403H-EI front panel
Table 1-11 Attributes of the fixed 100Base-T Ethernet ports on S2403H-EI front panel
Attribute Description
Connector RJ-45
Number of ports 25
Port attribute
10Mbps half/full duplex
100Mbps half/full duplex
Standard IEEE 802.3u
Max. transmission segment length over the
selected medium
100 m (328 ft) over the category-5 twisted pair cable
IV. Console port
S2403H-EI provides a Console port compliant with EIA/TIA-232 asynchronous serial
specifications. Through this port, you can configure the switch at the local or remotely.
Table 1-12 Console port attributes
Attribute Description
Connector RJ-45
Port standard Asynchronous EIA/TIA-232
Baud rate 9600 ( by default )
Service supported
z
Connection to the ASCII terminal
z
Connection to the serial port of a local terminal (which can be a PC) or a
remote terminal (through a pair of Modems) and running terminal
emulation program on the connected terminal
