UPS2000-G-15 kVA/20 kVA Dimensions
Figure 4-2 UPS2000-G-15 kVA/20 kVA installation dimensions
UPS Mounting Ear Dimensions
Figure 4-3 Dimensions of the mounting ears for the 6 kVA/10 kVA UPS
Figure 4-4 Dimensions of mounting ears for the 15 kVA/20 kVA UPS
Clearances
The distance between UPS air vents and the wall or obstacle is greater than or
equal to 500 mm.
UPS2000-G-(6 kVA–20 kVA)
User Manual (Lead-Acid Battery) 4 Installation
Issue 23 (2024-03-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 51
