Item Description
Ambient humidity Humidity detected by the ambient T/H sensor
(used together with an SNMP card; if the sensor is
not connected, N/A is displayed.)
Internal temp. Temperature of the air near the air intake vent of
the UPS
Runtime
Figure 5-17 Runtime screen
Table 5-13 Runtime
Item
Description
Inv. runtime Total time during which the UPS runs in inverter
mode
BPS runtime Total time during which the UPS runs in bypass
mode
5.6.2 Alarms
On the Main Menu screen, choose Alarms and press . The Alarms screen is
displayed.
When the buzzer buzzes, hold down for 2–5 seconds. The buzzer is muted when you
release the button. After the buzzer is muted, the alarm sound cannot be restored until a
new alarm is generated.
Active Alarms
This screen displays the active alarm information, such as the alarm serial number,
severity, ID, and name, as shown in Figure 5-18.
Figure 5-18 Active Alarms screen
UPS2000-G-(6 kVA–20 kVA)
User Manual (Lead-Acid Battery) 5 Control Panel
Issue 23 (2024-03-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 80
