Huawei UPS2000-G - Unpacking and Checking

Model Wiring
Termina
l
Numb
er of
Phases
Rated
Voltage
External
Circuit
Breaker
Cable
Cross-
Sectional
Area
Terminal
Type
Torque
for
Tighteni
ng Bolts
Output 1 220 V
AC/230 V
AC/240 V AC
125 A/2 P
(character
istic D)
25 mm
2
25 mm
2
M6 OT
terminal
4.8 N·m
20 kVA
(three-phase
input three-
phase
output)
Bypass
input
3 380 V
AC/400 V
AC/415 V AC
63 A/4 P
(character
istic D)
10 mm
2
10 mm
2
M6 OT
terminal
2.8 N·m
Mains
input
3
Battery - ± 240 V DC 63 A/4P
16 mm
2
16 mm
2
M6 90°
OT
terminal
4.8 N·m
Output 3 380 V
AC/400 V
AC/415 V AC
63 A/4 P
(character
istic D)
10 mm
2
10 mm
2
M6 OT
terminal
2.8 N·m
NO TE
● If customers purchase input and output power cables by themselves, use the cables that
comply with standards proposed by the Underwriters Laboratories (UL) or International
Electrotechnical Commission (IEC).
● Two power sources are not supported by the 15 kVA/20 kVA models with single-phase
input single-phase output.
4.1.4 Unpacking and Checking
Figure 4-6 shows the transportation safety requirements.
Figure 4-6 Transportation safety requirements
UPS2000-G-(6 kVA–20 kVA)
User Manual (Lead-Acid Battery) 4 Installation
Issue 23 (2024-03-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 59
