Mains Input
Figure 5-6 Mains Input screen
Table 5-5 Mains Input
Item Description
Van/Vbn/Vcn Mains input phase voltage (Voltage is displayed
when single-phase output mode is set.)
Frequency Mains input frequency
Vab/Vbc/Vca Mains input line voltage (The parameters are not
displayed in the case of single-phase input.)
Bypass Input
Figure 5-7 Bypass Input screen
Table 5-6 Bypass Input
Item
Description
Van/Vbn/Vcn Bypass input phase voltage (Voltage is displayed
when single-phase output mode is set.)
Frequency Bypass input frequency
Battery Status
Figure 5-8 Battery Status screen
