Open an Existing Configuration
1. Click the LOAD CONFIGURATION button. A list of existing configurations saved in the LOCAL
CONFIGURATIONS (WORKING) folder on the computer appears. Configurations sort and list by the
modified date, from newest to oldest (see Figure 7).
Figure 7. Load Configuration
2. Select the desired file name from the list and click LOAD.
NOTE: If the selected file was created in an earlier version of the E3 Console application, the INVALID
DATABASE VERSION warning screen (see Figure 8) displays. The E3 Console can upgrade the
configuration database to the correct version. The versions will change incrementally with the
release of new software.
Figure 8. Invalid Database Version
3. Click UPGRADE DATABASE to proceed with the configuration version upgrade; otherwise, select the
CLOSE button.
