Hubbell GAI-TRONICS E3 Console Manual

Pub. 42004-550A
Elemec3 Console Manual—Version 3.0 Page 28 of 114
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-550A.docx
09/20
Filter Speaker Remotes—drop down to filter the speaker remotes displayed in the list by system,
speaker master, and amplifier channel.
1. Set the address of each speaker remote on each amplifier channel.
The valid speaker remote address range is 0–32,767.
2. Change the description as appropriate for identification of the speaker remote.
3. Set the volume level for the speaker to LOWEST VOLUME, MID VOLUME, or HIGHEST VOLUME using
the drop-down list selector.
The speaker audio output power corresponds to the position of jumper P6 on the speaker remote
module and the volume level selected in the E3 Console:
Table 3. Speaker Audio Output Power
Speaker
Remote Model
Jumper P6
Position
E3 Console Volume
(TAP) Setting
Audio Output
Power
13317-001
(8-ohm, 25-watt)
High
Highest Volume
25 W
Mid Volume
12.5 W
Lowest Volume
6.25 W
Low
Highest Volume
6 W
Mid Volume
3 W
Lowest Volume
1.5 W
13317-002
(16-ohm, 30-watt)
High
Highest Volume
30 W
Mid Volume
15 W
Lowest Volume
7.5 W
Low
Highest Volume
6 W
Mid Volume
3 W
Lowest Volume
1.5 W
Remove Speaker Remote
1. Select the speaker remote from the list on the SPEAKER REMOTES SETUP screen.
2. Click REMOVE SELECTED.
A confirmation dialog box displays for confirmation.
3. Click REMOVE.
