Hunter XC Hybrid - LCD Display and Control Buttons

3
A – LCD DISPLAY
1. Run Times – Allows user to set each valve station
run time from 1 minute to 4 hours.
2.
Start Times – Allows 1 to 4 start times to be set in
each program.
3. Station Number – Indicates currently selected station
number.
4. Program Designator – Identifies program (A, B, or C)
in use.
5. Day of the Week – Identifies day of the week.
6.
Interval Watering – Identifies month when
programming current date.
7. Odd/Even Watering – Identifies if Odd or Even
watering has been selected.
8. Flashing Sprinkler – Indicates that watering is
taking place.
9.
System Off – Allows user to discontinue all
programs and watering. Also allows the user to
set the programmable "rain off," which stops
watering for a period from 1 to 7 days.
10.
Umbrella – Indicates that the rain sensor is active.
11.
Seasonal Adjustment – Allows the user to make
run time changes according to the seasons without
reprogramming the controller. Bars on the left allow
quick visual reference to the seasonal adjustment
percentage.
12.
Rain Drop – Indicates watering will occur on the
selected day.
13.
Crossed Rain Drop – Indicates the watering will
NOT occur on the selected day.
14.
Calendar – Indicates interval watering schedule
has been programmed. Icon also appears when
programming the current day.
B – WIRING COMPARTMENT
15. Terminal Strip – Use to attach transformer, sensor,
and valve wires from their source to the controller.
16. Reset Button – Use to reset the controller.
17. Battery Holder – Holds six AA alkaline batteries.
C  CONTROL BUTTONS
Button – Increases the selected item ashing in the
display.
Button – Decreases the selected item flashing in the
display.
Button – Returns selected flashing display to previous
item.
Button – Advances the selected flashing display to the
next item.
Button – Selects program A, B, or C for different
watering zone requirements.
18. Sensor Bypass Switch.
