INSTALLATION
20
18V DC Power Supply
NOTE: When power is connected to the motor, a blue LED inside
the control button housing will flash to indicate the shading is ready
for operation.
■
Plug the power cable from the shading motor into the extension cable.
■
Plug the other end of the extension cable into the 18V DC power supply.
■
Plug the 18V DC power supply into the power source.
Proceed to “Operate the Shading” on page 21.
Power cable
from shading motor
Extension
cable
18V DC
Power
Supply
To Next Page
