Automower from 53
3. Installation
™
Example number 2
In this example the guide loop is longer than 200 metres. There is a risk that the Automower stops
following the guide wire. The charging station should therefore be moved.
In the figure below, the charging station has been moved to the outer edge of the working area. The guide
loop is now shorter than 200
metres and there is a large open area in front of the charging station. The
delay time for the boundary wire is set to 99
minutes, that is to say, deactivated, which reduces the risk of
tracks forming. Automower will find the charging station through the Irregular search method or by
following the guide wire.
Follow loop Boundary wire Guide wire Follow loop out Area 1
Delay 11 minutes 7 minutes Direction Guide
Corridor width 6 10 Distance 30 metres
Proportion 30%
Follow loop Boundary wire Guide wire Follow loop out Area 1
Delay 99 minutes 7 minutes Direction Guide
Corridor width 6 10 Distance 30 metres
Proportion 30%
3012-621
2m
2m
3m
1
Non approved
3012-623
2m
2m
3m
1
Fully approved
10
