58 Automower from
3. Installation
™
Example number 7
In this example Automower, with the help of the settings, will reach the entire working area.
Example number 8
In this example Corridor width 1 is required for the mower to pass through the passages. The installation is
approved, but can be designed better. Both another charging station placement and a guide wire are
recommended.
Follow loop Boundary wire Guide wire Follow loop out Area 1 Area 2
Delay 11 minutes 7 minutes Direction Left Left
Corridor width 6 6 Distance 30 metres 15 metres
Proportion 20% 40%
Follow loop Boundary wire Guide wire Follow loop out Area 1 Area 2
Delay 11 minutes 7 minutes Direction Left Left
Corridor width 1 6 Distance 30 metres 15 metres
Proportion 20% 40%
3012-633
3m
3m
1
Fully approved
2
3012-646
1.5m
1
Approved
2
1.5m
