3. Installation
™
Example number 6
In this example the charging station is placed by an island. The easiest way to reach Area 1 is with the help
of the Exit angles function.
The working area contains many islands, which results in long search times. By increasing the corridor
width for the boundary wire, the search times are reduced, as the mower will then run past unnecessary
passages. However this does suggest a risk of tracks forming. Consequently, a guide wire is
recommended.
Follow loop Boundary wire Guide wire Exit angles Area 1, 2
Delay 20 minutes 7 minutes Start angle 1 – End angle 1 (2) 90° and 200°
Corridor width 10 6 Start angle 2 – End angle 2 (1) 240° and 270°
Proportion first 40%
3012-630
3m
4m
3m
1
Fully approved
2
6
10
