56 Automower from
3. Installation
™
Example number 5
In this example the guide loop is longer than 200 metres. There is a risk that the Automower stops
following the guide wire. The charging station should therefore be moved.
In the figure below, the charging station is placed in a corresponding position in Area 2. The guide loop will
then be shorter than 200
metres. By increasing the corridor width for the boundary wire the mower, when
searching, will run past several passages instead of running through them.
Follow loop Boundary wire Guide wire Follow loop out Area 1
Delay 11 minutes 7 minutes Direction Guide
Corridor width 6 6 Distance 10 metres
Proportion 50%
Follow loop Boundary wire Guide wire Follow loop out Area 1
Delay 11 minutes 7 minutes Direction Guide
Corridor width 15 6 Distance 10 metres
Proportion 50%
3012-628
3m
1m
3m
1
Non approved
3012-629
3m
1m
3m
1
Fully approved
15
15
2
