Automower from 55
3. Installation
™
Example number 4
In this example a Corridor width 0 is required for the mower to pass through the passage. This setting
requires the boundary wire to be at least 40cm inside the working area, which the passage is too narrow
for. The working area also contains many islands, which makes it inappropriate to allow the mower to
follow the boundary wire. In order for the mower to easily pass through the passage, to avoid tracks
forming and to get shorter search times, a guide wire through the passage is recommended.
With the help of a guide wire, the Automower finds the charging station easily from Area 1. On the other
hand, there is a risk of the mower not finding its way out of the area if it does not find the guide wire and
start to follow it before the delay time for the boundary wire has elapsed. From Area
2 the Automower will
normally find the charging station by using the Irregular search method. With an increased corridor width
for the boundary wire the mower, when searching, will run past several passages instead of running
through them, which is an advantage in Area
2.
Follow loop Boundary wire Guide wire Follow loop out Area 1
Delay 11 minutes 7 minutes Direction Right
Corridor width 0 6 Distance 10 metres
Proportion 50%
Follow loop Boundary wire Guide wire Follow loop out Area 1
Delay 18 minutes 3 minutes Direction Guide
Corridor width 15 6 Distance 10 metres
Proportion 50%
3012-626
3m
1m
3m
1
Non approved
2
3012-627
3m
1m
3m
1
Fully approved
6
15
15
2
