HUST H2N Connection Manual
6 - 24
Table 6-4 Registers and Corresponding Variables for HUST H2N Controller
Register Variable No. Application / Definition
R100 10100 Execution mode selection
R160~R161 10160~10161 Feed-rate setting for X and Y-axis
R180~R181 10180~10181 Absolute Coordinate setting for X and Y-axis
R190 10190 Type of motor deceleration selection for G31 skip function
R200 10200 Page number for Liquid LCD Screen display
R220 10220 Feed-rate percentage (%) for G00 (G00 MFO %)
R221 10221 Feed-rate percentage (%) for G01, G02, G03
R222 10222 Multiplication factor for MPG pulse (MPG MFO %)
R223 10223 Spindle Gear ratio
R224 10224 When C121=0, spindle speed percentage (%) = value in R224
R225 10225 When C121=1, spindle speed percentage (%) = value in R225
R226 10226 Selecting program number from external I/O device
R227 10227 The selected variable number when editing the variable data
R228 10228 Selecting work coordinate system
R229 10229 Setting the number of decimals for display after power on
R230 10230 Page number for Man Machine Interface display
R231 10231 Reserved
R232 10232 For selecting the axis in JOG and HOME mode
R233 10233 For selecting the axis in JOG and MPG mode, (+) direction
R234 10234 For selecting the axis in JOG and MPG mode, (-) direction
* R235 10235 For displaying the axis that is drivable (enabled)
* R236 10236 For displaying the axis that is on HOME location (machine zero)
* R237 10237 For displaying the axis of which the HOME operation has been executed
R238 10238 For selecting the axis to be the spindle axis
* R241 10241 Storing the keyboard key code as read by the controller
R242 10242 Storing the desired output key code
R250 10250 Input signal type for G31
* R251 10251 For storing the ERROR code
* R252 10252 For storing current M-code
* R253 10253 For storing current T-code
* R254 10254 For storing current S-code
* R255 10255 For storing the current program number
* Data in these registers are “READ only”.
