HUST H2N Connection Manual
6 - 28
Ex: R232 = 3 (=11 in binary), Bits 0, 1 are ON. If you execute HOME operation
(C063=1), both X and Y-axis will move simultaneously. If you execute JOG,
both axes (X and Y) will move simultaneously.
R233, For selecting the axis for JOG feed in positive (+) direction
When in JOG mode and C228=1, use R233 Bit-0 ~ Bit-1 to select the axis for
JOG operation in the positive (+) direction. The value in R233 will affect the
direction of MPG. So please set R233=0 when not in use. The JOG speed will be
by MCM #44~#45.
When C228 =1, R233 =1, X-axis will move in (+) direction with JOD speed.
When C228 =1, R233 =2, Y-axis will move in (+) direction with JOD speed.
When C228 =1, R233 =3, X and Y-axis will move in (+) direction with JOD
speed.
Ex: R233 = 3 (=11 in binary), Bits 1 and 0 are ON. So, if you execute JOG and
C228=1, both X and Y-axis will move simultaneously in the positive (+)
direction.
R234, For selecting the axis for JOG feed in negative (-) direction
When in JOG mode and C228=1, use R234 Bit-0 ~ Bit-1 to select the axis for
JOG operation in the negative (-) direction. The value in R234 will affect the
direction of MPG. So please set R234=0 when not in use. The JOG speed will be
by MCM #44~#45.
When C228 =1, R234 =1, X-axis will move in (-) direction with JOD speed.
When C228 =1, R234 =2, Y-axis will move in (-) direction with JOD speed.
When C228 =1, R234 =3, X and Y-axis will move in (-) direction with JOD speed.
Ex: R234 = 3 (=11 in binary), Bits 1 and 0 are ON. So, if you execute JOG and
C228=1, both X and Y-axis will move simultaneously in the negative (-)
direction.
R235, For displaying the axis that is drivable (enabled)
Use R235 to display the drivable axis. This is a system-defined parameter and
presented here for read only. Do not attempt to change the value in R235.
When R235 = 1 → Bit 1=0 & Bit 0=1, X-axis is usable.
When R235 = 2 → Bit 1=1 & Bit 0=0, Y-axis is usable.
When R235 = 3 → Bit 1=1 & Bit 0=1, both X and Y-axis are usable.
