9 Appendix A
9 - 3
Table A1 Command Format Representation
Item "On" Switch (1) Position
No 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16~19 20 21 22 23 24 25 26 27 28 29
*1 N 1
*2 N 0 1
3 N 0 0 1
4 N 0 0 0 1
5 N 0 0 0 0 1
6 N 0 0 0 0 0 1
7 N 0 0 0 0 0 0 1
8 N 0 0 0 0 0 0 0 1
9 N 0 0 0 0 0 0 0 0 1
10 N 0 0 0 0 0 0 0 0 0 1
11 N 0 0 0 0 0 0 0 0 0 0 1
12 N 0 0 0 0 0 0 0 0 0 0 0 1
*13 N 1 0 0 0 0 0 0 0 0 0 0 0 1
*14 N 1 0 0 0 0 0 0 0 0 0 0 0 0 1
15 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
20 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
21 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
22 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
23 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
24 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
25 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
26 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
27 N 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
*28 N 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
*29 N 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
* Format is fixed for these commands.
Notes:
1. For Item No's 13, 14, 28 and 29, the "stop report" switch (1) must be On also.
2. For Items with '*', command format is fixed (only 1 request). For Items without
'*', more than one command can be requested at a time.
For example, if request the data for program position (Item 7) and machine
position (Item 8) at the same time, the command sequence is N00000011.
The meanings of command representations with corresponding item numbers
mentioned above are tabulated in Table A2.
