2.6
MANUAL MODE (Green light)
Enables all control switches and PLC function buttons. Also stops an automatic job in progress by
switching to MANUAL.
AUTO MODE (Red light)
Puts the machine in AUTO MODE and disables all manual functions. The front vise selector
switch must be in the closed position.
AUTO
MAN
•
REV
•
90
•
FWD
•
MANUAL MODE
This key will advance the shuttle toward the head (home position).
AUTO MODE
Key is disabled.
MANUAL MODE
This key will retract the shuttle away from the head.
AUTO MODE
Key is disabled.
MANUAL MODE
This key will swing the head toward 90 degrees.
AUTO MODE
Key is disabled.
30
•
SLOW
FAST
•
MANUAL MODE
This key will swing the head toward 30 degrees.
AUTO MODE
Key is disabled.
MANUAL MODE
Green light indicates that the shuttle movement and head swing will move at a slow speed.
Red light indicates that the same movements will be at a fast speed.
AUTO MODE
Key is disabled.
INCH
METRIC
•
MANUAL MODE/AUTO MODE
Green light indicates Imperial values.
Red light indicates Metric values.
FUNCTION BUTTON DESCRIPTION
On the dual function buttons, if a green indicator light is illuminated, it means that the function printed in green on the top
of the button is enabled. A red light indicates the function printed in red at the bottom of that button is enabled.
PARA-
METERS
•
PARAMETERS
Password screen.
Entering the password allows access to parameter values.
