3.6
LUBRICATION
The design of the M-16, M-20 is intended to minimize maintenance, although periodically certain moving parts do require
lubrication. We recommend that this periodic lubrication be done once a month using any general-purpose grease.
In addition to the grease points shown, vise jaw guides, infeed rollers and bundling assemblies require greasing.
Head Pivot Idler wheel tensioner Shuttle house shafts
2 lube points on xed vise shafts
plus
2 lube points on shuttle vise shafts.
Bundling option.
1 on each bundling shafts
