Hydmech M16A - M16 Hydraulic Assembly Component List

5.2
18 1 DCV3P-AB-T Shuttle Valve
19 1 DCV3P-AB-T Guide Arm Valve
20 1 DCV3P-AB-C Front Vise Valve
21 1 DCV3P-AB-C Shuttle Vise Valve
22 1 DCV3P-AB-T Swing valve
23 1 DCV3P-AB-C Outboard Vise (Option)
24 2 PV2P-A-C Poppet Valve
25 1 CHB-25C Cushion Block, shuttle
26 1 HP-1 Pump
27 1 SS-100-00 Suction Strainer
28 1 SF6520 Return Filter
29 1 HM-1 Chip Conveyor Motor
30 1 N10BK Needle Valve
31 1 CHB-15C Cushion Block, swing
32 1 JB-02B Double Junction Block (Option)
33 1 PRV1/12 Pressure Reducing Valve (Option)
34 1 EB-02 Extension Block, Left (Option)
M16 HYDRAULIC ASSEMBLY COMPONENT LIST
ITEM QTY M20 PART NUMBER DESCRIPTION
1 1 M16-C4-00B Head Cylinder
2 1 M16-C1-00A Shuttle Cylinder
3 1 S25-C5-00 Blade Tension Cylinder
4 1 M20-C21-00A Front Vise Cylinder
5 1 M20-C21-00A Shuttle Vise Cylinder
6 1 M16-C22-00B Datum Vise Cylinder
7 2 M20-C23-00B Bundling Clamp Cylinder (Optional)
8 1 M16-C6-00B Guide Arm Cylinder
9 1 M16-C7-00 Swing Cylinder
10 1 DDF21-0-00 Positive Downfeed Valve
11 1 MB6PA Manifold Block
12 1 EB-01A Manifold Extension Block
13 4 DPCH-1 Double Pilot Check
14 3 PG-10 Pressure Gauge (1000 psi)
15 1 PG-10 Pressure Gauge (1000 psi, VVP option)
16 1 DCV3P-AB-T Head Lift Valve
17 1 DCV3P-AB-C Blade Tension Valve
18 1 DCV3P-AB-T Shuttle Valve
19 1 DCV3P-AB-T Guide Arm Valve
20 1 DCV3P-AB-C Front Vise Valve
21 1 DCV3P-AB-C Shuttle Vise Valve
