Hydmech M16A User Manual

8.3
M20A SPECIFICATIONS
Overall Dimensions 135" (3429mm) Wide, 90" (2286mm) Long, 64 x (1626mm) High
Machine Weight
7700lbs(3493Kg)
MachineWorkload
8000 lbs (3629 Kg)
Shuttle Stroke
0-33" (0-838mm) single stroke, multi-indexing capability
Table Height 32" (812mm)
BladeTensionPressure 950PSI(6550kPa)
Vise Control
Hydraulic
Hydraulic Tank
11 U.S. Gallons (42 Liters)
HydraulicSystem 950PSI(6550kPa)
Pumps
Hydraulic 6 1/2 Gal / min (24.5 Liters/min) pressure compensated
Coolant 3 1/2 Gal / min (13.2 Liters/min) (150W)
Blade Wheel Dia. 22" (559mm)
Drive
blade drive 10 hp (7.5 kW)
hydraulic pump drive 3 hp (2.2 kW)
Blade Speed 60 - 350 sf/min (18 - 107 m/min)
Blade Guides carbide inserts (water soluble coolant lubricated)
.050"(1.25mm)
Blade Tension Hydraulic
Length Control
Programmable up to 99 jobs, with 5 in queue.
Blade
Length 20'-6" (23'-2" w/extended head) 6250mm (7061mm)
Width 1 1/2" (38mm)
Thickness
Capacity: 45°
rectangular 18" (457mm) wide x 20" (508mm) high
round 20" (508mm) dia
Capacity: 30
°
rectangular 12" (305mm) wide x 20" (508mm) high
round 12" (305mm) dia
M-20A BANDSAW SPECIFICATIONS
Capacity: 90°
rectangular 20" (508mm) wide x 30" (762mm) high
round 20" (508mm) dia

Hydmech M16A Specifications

General

Brand	Hydmech
Model	M16A
Category	Industrial Equipment
Language	English
