Page 78
XX
Lost Ground Con-
trol
• Communication between main board and
display is disturbed
•
•
Check cable between mainboard
and display
Check RS485 interface
modules
X
Maintenance
The system
switches off after
60 min. in opera-
tion in cylinder full
condition.
• Unit requires maintenance:
- Cylinder full of scale deposits wich limit the
electrodes immersion depth.
- Electrodes worn out.
•
•
Clean steam cylinder and elec-
trodes or replace electrodes.
Replace electrodes. (If electrode
wear is high, see note in section
„Electrode Exchange“ in unit hand-
book)
• Phase defective (external fuse faulty). • Replace fuse.
• With very low water conductivity continuous
steam production is insufficient in order to
concentrate and raise the water conductivity.
• Establish water values and/or con-
tact HygroMatik about the problem.
XX
Maintenance K1
The system still op-
erates. The green
LED flashes rapid-
ly.
• According to manufacturer specification 90%
of the electrical lifetime is achieved. To avoid
failure, a replacement of the main contactor is
recommended in the short term.
•
•
Replace main contactor.
See parameter description "P11 re-
set main contactor interval" for
Comfort / Comfort Plus control or
"Brief Description of Jumpers" for
Basic control..
XX
Safety stop • Parameter D5 for limitation of operating time
is activated. The steam generator stopped
operation after the safety interlock has been
closed for the time programmed under
parameter D5.
• By opening and closing the safety
interlock the steam generator
restarts operation for the pro-
grammed hours (D5).
Alternatively set parameter D5 to 0
and restart system. The function
„limitation of operating time” is
deactivated.
HL ***
Hy,C***
Possible Condi-
tions
Probable Cause for fault situation Resolution
XX
Water is collecting
on the base plate
• Zylinder nach der Wartung falsch zusam-
mengebaut:
- O-Ring beschädigt, nicht getauscht oder
nicht eingesetzt
-Flansch (Nut/Feder) beschädigt
-Flansch nicht richtig verschlossen
-Härtebildner im Flansch
• Clean cylinder and install properly.
• The cylinder is incorrectly placed on the base. • Lay a moistened new o-ring in the
base and then insert the cylinder.
• The water cannot drain away during flushing. • Make sure drain is unobstructed.
LED Dis-
play
HL ***
Hy,C***
Message / Mal-
function Dis-
played*
Probable Cause Resolution
