Hypertherm HPR130 User Manual

OPERATION
5
4-20 HPR130 Manual Gas Instruction Manual
Aluminum
Air Plasma / Air Shield
130 A Cutting
220198220173 220181220176 220179220197
Note: This process produces a rougher cut edge that is less perpendicular than the 130 A, H35/N
2
process
Flow rates – lpm/scfh
Air
Preflow 73 / 154
Cutflow 78 / 165
Metric
English
Select
Gases
Set
Preflow
Set
Cutflow
Material
Thickness
Arc
Voltage
Torch-to-Work
Distance
Cutting
Speed
Initial Pierce
Height
Pierce Delay
Time
Plasma Shield Plasma Shield Plasma Shield
mm
Volts mm mm/m mm factor % seconds
Air Air 20 40 70 30
6
153 2.8 2370 5.6
200
0.2
10
154
3.0
1465
6.0
0.3
12
156 1225 0.5
15
158 3.3 1050 6.6 0.8
20
162 3.5 725 7.0 1.3
25
172 4.0 525 N/A
Select
Gases
Set
Preflow
Set
Cutflow
Material
Thickness
Arc
Voltage
Torch-to-Work
Distance
Cutting
Speed
Initial Pierce
Height
Pierce Delay
Time
Plasma Shield Plasma Shield Plasma Shield
in
Volts in ipm in factor % seconds
Air Air 20 40 70 30
1/4
153 0.110 90 0.220
200
0.2
3/8
154
0.120
60
0.240
0.3
1/2
156 45 0.5
5/8
158 0.130 40 0.260 0.8
3/4
162 0.140 30 0.280 1.3
1
172 0.160 20 N/A
Select
Gases
Set
Preflow
Set
Cutflow
Amperage
Torch-to-Work
Distance
Marking
Speed
Arc
Voltage
Amps
mm in mm/min ipm Volts
N
2
N
2
10 10 10 10
18
2.5 0.100 6350 250 120
Marking
