Appendix B – CnC interfACe protoCol
HPR130XD Auto Gas – 806330 Revision 1 b-23
ID Name Description
106 Primary
306 Secondary
CURRENT TOO LOW ON LEM
#2
A current less than 10 amperes has been detected by current
sensor 2.
107 Primary
307 Secondary
CURRENT TOO HIGH ON LEM
#3
A current greater than 35 amperes has been detected by current
sensor 3.
108 Primary
308 Secondary
TRANSFER AT INIT
The system has detected current on the work lead during
power-up.
109 COOLANT FLOW AT INIT
Coolant flow is greater than 1.14 lpm (0.3 gpm) when pump is
off.
111 COOLANT OVERTEMP AT INIT Coolant is indicating overtemp during power-up.
116 Primary
316 Secondary
WATCHDOG INTERLOCK CAN communication error.
123 MV 1 ERROR Motor valve 1 did not move into position within 60 seconds.
124 MV 2 ERROR Motor valve 2 did not move into position within 60 seconds.
133
UNKNOWN GAS CONSOLE
TYPE
The power supply control board does not recognize the gas
console installed or has not received a CAN message identifying
the type of console installed.
134 Primary
334 Secondary
CHOPPER 1 OVERCURRENT Chopper 1 current feedback has exceeded 160 amperes.
138 Primary
338 Secondary
CHOPPER 2 OVERCURRENT Chopper 2 current feedback has exceeded 160 amperes.
139 PURGE TIMEOUT ERROR The purge cycle did not complete within 3 minutes.
140
AUTO GAS PRESSURE
TRANSDUCER #1 ERROR
Faulty transducer or auto gas control PCB
141
AUTO GAS PRESSURE
TRANSDUCER #2 ERROR
Faulty transducer or auto gas control PCB
142
AUTO GAS PRESSURE
TRANSDUCER #3 ERROR
Faulty transducer or auto gas control PCB
143
AUTO GAS PRESSURE
TRANSDUCER #4 ERROR
Faulty transducer or auto gas control PCB
144
MANUAL GAS CONSOLE
INTERNAL FLASH MEMORY
ERROR
Replace manual gas console control PCB
145
AUTOMATIC GAS CONSOLE
INTERNAL FLASH MEMORY
ERROR
Replace auto gas console control PCB
146 Primary
346 Secondary
CHOPPER #3 OVERTEMP AT
INIT
Chopper #3 is indicating over temp during power-up
147 Primary
347 Secondary
CHOPPER #4 OVERTEMP AT
INIT
Chopper #4 is indicating over temp during power-up
151 Primary
351 Secondary
SOFTWARE FAIL Software has detected an incorrect state or condition.
152 INTERNAL FLASH ERROR DSP memory is not working properly.
153 PS EEPROM ERROR EEPROM memory on power supply board not working.
154 Primary
354 Secondary
CHOPPER 3 OVER CURRENT Chopper 3 current feedback has exceeded 160 amperes
155 Primary
355 Secondary
CHOPPER 4 OVER CURRENT Chopper 4 current feedback has exceeded 160 amperes
