InstallatIon
3-50 HPR130XD Auto Gas – 806330
Fill the power supply with coolant
The system will take 11.4 – 15.1 liters (3 to 4 gallons) of coolant depending on the length of the torch leads and
whether the system has a local or remote ignition console.
3. Locate the CNC screen for manual pump
control. The pump needs to run to fill the leads.
4. Add coolant to the power supply until
the tank is full and replace the filler cap.
1. Add coolant to the power supply until the
tank is full.
2. Turn ON the power supply using the remote
ON/OFF switch or the CNC.
Caution: Using the wrong coolant can cause damage to the system. Refer to torch
coolant requirements in this section for more information.
Do not over fill the coolant tank.
