InstallatIon

HPR130XD Auto Gas – 806330 3-19

Ignition console coolant hoses

Red

Green

Red

* Hose set number 228030 is for use with systems that have the ignition console mounted on the power supply

Part no. Length Part no. Length

228030* 0.7 m (2.5 ft) 128984 20 m (65 ft)

028652 3 m (10 ft) 128078 25 m (85 ft)

028440 4.5 m (15 ft) 028896 35 m (115 ft)

028441 7.5 m (25 ft) 028445 45 m (150 ft)

128173 10 m (35 ft) 028637 60 m (200 ft)

028442 15 m (50 ft) 128985 75 m (250 ft)

Caution: Never use PTFE

tape on any joint

preparation.
