SOFTWARE FUNCTIONAL DESCRIPTION
HPR400XD Manual Gas Instruction Manual b-3
• If no chopper current after 10 HF pulses, go to Auto Off state with error code (020), “No pilot arc.”
Error checking
• No error checking due to HF noise.
6. Transfer
• If work lead current is > transfer reference current, go to Ramp-up state and turn off pilot arc controller
and pilot arc relay.
• If no transfer after 500 milliseconds, go to Auto Off state with error code (021), “No arc transfer.”
• If chopper current is < 1⁄2 of setpoint, turn on HF.
Error checking
• No error checking due to HF noise.
7. Ramp-up
• If Pierce-complete input is off, then switch to cutflow gases.
• Ramp-up current is based on tables.
• Once chopper current is = or > setpoint, go to Steady state.
Error checking
• Check for coolant flow at power-up (093).
• Check for over/under line voltage (047/046).
• Check for coolant over temperature (071).
• Check for chopper over temperature on all choppers (065, 066, 073, 074).
• Check for transformer over temperature (067).
8. Steady state
• If Pierce-complete input is off, then switch to cutflow gases.
• If corner-current input is on, then switch to corner-current setpoint.
• If start-signal input is off, then go to Ramp-down state.
Error checking
• Check for loss of phase (027).
• Check for coolant flow at power-up (093).
• Check for over/under line voltage (047/046).
• Check for coolant over temperature (071).
• Check for chopper over temperature on all choppers (065, 066, 073, 074).
• Check for transformer over temperature (067).
• If chopper current is < 5 amps, show current lost error (024-CH1, 025-CH2, 028-CH3, 034-CH4).
• If work lead current < 5 amps, show transfer lost error (026).
9. Ramp-down
• Do current ramp-down according to tables.
• Put gas console into Idle state or Ramp-down state according to tables.
• Once current reaches end current, go to final Ramp-down state.
Error checking
• Check for coolant flow at power-up (093).
