Installer Menu
3-28 SlideSmart DC Installation and Reference Manual Revision D
25
0 = Pause closing only
1 = Enable reversing to open
The default is for full reversal when the Outside Obstruction Loop is triggered. A setting of 0 causes the gate to only pause when triggered. Gate closure begins as soon as the loop is clear again.
OUTSIDE OBS LOOP COM or HY-5A
26
0
=
Pause closing only
1 = Enable reversing to open
The default is for full reversal when the Inside Obstruction Loop is triggered. A setting of 0 causes the gate to only pause when triggered. Closure begins as soon as the loop is clear again.
INSIDE OBS LOOP COM or HY-5A
27
1 = Standard 2
=
Quick close
3
=
Forced Time out
4
=
Full anti-tailgate
Configures for faster closure. This selection determines whether the close timer begins to count after vehicles have departed the detector loops or whether the close timer will count down while the loops are occupied. The gate can only close when all loop detectors are not triggered. Refer to
Vehicle Detector Configuration and Quick Close Mode
Selection
.
HY-5A
28
0 = default 1 to 25 available
Configures the function of the user 1 output relay, which is a large mechanical relay. It has the capacity to switch both AC and DC and can be used for high voltage and/or high current loads. Connect devices directly to the top of the relay: COM plus NO and NC contacts. Twenty four optional logic functions exist. See
Setting the
User Relay Function in the Installer Menu
.
User 1 Relay
Table 3-2. Smart DC Controller - Installer Menu Functions (Continued)
Ref. No. *
Installer Menu
Setting Options (
Bold = Factory Settings
) Tasks and Explanations
Associated DC Controller Connections
Display
OR 1 REVERSE OUTSIDE OBS LOOP
IR 1 REVERSE INSIDE OBS LOOP
DL 1 STANDARD DETECTOR LOGIC
RL 1 0 DISABLED RELAY 1 LOGIC
