Service Manual UHF1 (400-470MHz) Information
109
No. Ref. No. Print No. Part No. Description
923 U607 T5J 3609010000170 Reset IC
924 U608 B3E 3608006000000 Power management IC
925 U609 T2J 3608006000000 Power management IC
926 U610 T3I 3608006000030 Power management IC
927 U611 T4H 3608011000050 Power management IC
928 U612 B1J 3608006000000 Power management IC
929 U701 T1K 3606010000010 D/A converter
930 U801 T4K 3602023005740 Audio amplifier
931 U820 T2L 3616037000020 Switch IC
932 U821 T2K 3613010000000 Baseband processor
933 U9002 B1E 3605025000020 Operational amplifier
934 U9003 B1D 5404000000060 Sensor
935 X101 T1I 3701019250030 TCXO 19.2MHZ
936 X201 B5J 3701327610060 Crystal 32.768KHz
937 X203 B3H 3701019250040 TCXO 19.2MHz
938 Z501 B3C 3804157560000 GPS filter
939 Z9001 B3F 3802733540020 Crystal filter
940 / / 6201809000000 Shielding can for IF processor
941 / / 6201810000000 Shielding can for baseband processor
942 / / 6201859000000 Shielding frame for lowpass filter
943 / / 6201860000000 Shielding frame for GPS
