Hytera PD78XG Service Manual

UHF1 (400-470MHz) Information Service Manual
110
No. Ref. No. Print No. Part No. Description
944 / / 6201862000000 Shielding can for TX VCO
945 / / 6201865000000 Shielding can for crystal oscillator
946 / / 6201915000000 Shielding can for antenna spring plate
947 / / 6201935000000 Shielding can for switching power
948 / / / Main board
PD70X/ PD70XG/ HD705/ HD705G Channel Board
No. Ref. No. Part No. Description
1 R1002 3001051210010 120Ω
2 C1001 3101052710000 270PF
3 C1002 3101052710000 270PF
4 C1003 3101052710000 270PF
5 C1004 3101052710000 270PF
6 C1005 3101052710000 270PF
7 C1006 3101052710000 270PF
8 C1007 3101052710000 270PF
9 C1010 3101052710000 270PF
10 C1011 3101052710000 270PF
11 C1012 3101052710000 270PF
12 D1001 3310040000000 ESD protection diode
13 D1003 3310040000000 ESD protection diode
14 D1004 3310040000000 ESD protection diode
15 D1005 3310040000000 ESD protection diode

Hytera PD78XG Specifications

General

Brand	Hytera
Model	PD78XG
Category	Portable Radio
Language	English
