Hytera PD78XG Service Manual

UHF2 (450-520MHz) Information Service Manual
198
No. Ref. No. Print No. Part No. Description
923 R9089 T5D 3001055620000 5.6KΩ
924 R9090 T4C 3001051030050 10KΩ
925 R9095 T3F 3001053320000 3.3KΩ
926 R9096 T3F 3001053320000 3.3KΩ
927 R9097 T2F 3001053320000 3.3KΩ
928 R9098 T2F 3001053320000 3.3KΩ
929 R9099 B1E 3101051010030 100PF
930 R9100 B1D 3101051010030 100PF
931 RN256 B3J 3005051030010 10KΩ
932 RN261 B5K 3001052230020 22K*2
933 T9001 T4E 5406000000200 Transformer
934 T9002 / 5406000000200 Transformer
935 U101 B1I 3616059000000 Switch IC
936 U102 B1I 3605002057290 Operational amplifier
937 U103 T1I 3604019000000 PLL IC
938 U104 B1I 3616059000000 Switch IC
939 U201 B3I 3610010000010 MCU
940 U242 B2J 3612044000010 Memory
941 U244 B4I 3612002000020 Memory
942 U312 B4L 3805000000030 EMI filter
943 U313 B5E 3805000000030 EMI filter
