Hytera PD78XG Service Manual

Service Manual UHF2 (450-520MHz) Information
199
No. Ref. No. Print No. Part No. Description
944 U314 B4K 3805000000030 EMI filter
945 U315 B4G 3805000000030 EMI filter
946 U316 B4F 3805000000030 EMI filter
947 U317 B4G 3805000000030 EMI filter
948 U318 B4F 3805000000030 EMI filter
949 U319 B4D 3805000000030 EMI filter
950 U320 B3K 3805000000030 EMI filter
951 U321 B3L 3805000000030 EMI filter
952 U322 B3L 3805000000030 EMI filter
953 U401 T3H 3603999000000 IF processor
954 U501 B3C 3609999000300 GPS LNA
955 U502 B3D 1615000001720 GPS module
956 U601 T4G 3608011000050 DC-DC
957 U604 B3F 3608020005750 Power management IC
958 U605 B2F 3608020005750 Power management IC
959 U606 T3J 3608006000000 Power management IC
960 U607 T5J 3609010000170 Reset IC
961 U608 B3E 3608006000000 Power management IC
962 U609 T5I 3608006000000 Power management IC
963 U610 T2I 3608006000030 Power management IC
964 U611 T4H 3608011000050 DC-DC
