UHF2 (450-520MHz) Information Service Manual
200
No. Ref. No. Print No. Part No. Description
965 U612 B1J 3608006000000 Power management IC
966 U701 T1K 3606010000010 D/A converter
967 U801 T4K 3602023005740 Audio amplifier
968 U820 T2L 3616037000020 Switch IC
969 U821 T2K 3613010000000 Baseband processor
970 U9002 B1E 3605025000020 Operational amplifier
971 U9003 B1D 5404000000060 Temperature sensor
972 X101 T1I 3701019250030 TCXO
973 X201 B5J 3701327610060 Crystal
974 X203 B3H 3701019250040 TCXO
975 Z501 B3C 3804157560000 GPS filter
976 Z9001 B3F 3802733540030 Crystal filter
977 / / 6201810000000 Shielding can for baseband processor
978 / / 6201860000000 Shielding frame for GPS
979 / / 6201865000000 Shielding can for crystal oscillator
980 / / 6201915000000 Shielding can for antenna spring plate
981 / / 6201935000000 Shielding can for switching power
982 / / 6201859000000 Shielding frame for lowpass filter
983 / / 6201862000000 Shielding can for TX VCO
984 / / / Main board
