Hytera PD78XG Service Manual

Service Manual UHF2 (450-520MHz) Information
201
PD70X/ PD70XG/ HD705/ HD705G Channel Board
No. Ref. No. Part No. Description
1 R1002 3001051210010 120Ω
2 C1001 3101052710000 270PF
3 C1002 3101052710000 270PF
4 C1003 3101052710000 270PF
5 C1004 3101052710000 270PF
6 C1005 3101052710000 270PF
7 C1006 3101052710000 270PF
8 C1007 3101052710000 270PF
9 C1010 3101052710000 270PF
10 C1011 3101052710000 270PF
11 C1012 3101052710000 270PF
12 D1001 3310040000000 ESD protection diode
13 D1003 3310040000000 ESD protection diode
14 D1004 3310040000000 ESD protection diode
15 D1005 3310040000000 ESD protection diode
16 D1006 3310040000000 ESD protection diode
17 D1007 3310040000000 ESD protection diode
18 D1008 3310040000000 ESD protection diode
19 D1011 3310040000000 ESD protection diode
20 D1014 3310040000000 ESD protection diode
21 D1009 3399040600020 ESD protection diode
22 D1013 3399040600020 ESD protection diode
23 D1002 3307120100050 LED
